Del Ozone DEL AOP 25 UV and Ozone System For Pools Up to 25K Gals (120 /240 V)

DEL Ozone's AOP 25 combines Ozone and Germicidal UV for the safest, cleanest swimming pool water. This innovative, advanced sanitation system creates a synergy so pool water is more effectively disinfected than with Ozone, Germicidal UV, or Chlorine alone.

AOP stands for Advanced Oxidation Process, which refers to a variety of chemical treatments that sanitize and disinfect water by oxidizing organic and inorganic contaminants upon contact. The concept is similar to the use of ozone for disinfection, but AOPs go beyond standard treatment methods because they produce hydroxyl free radicals (●OH). AOPs are created inside AOP systems where ozone and UV collide.

Hydroxyl free radicals have a higher oxidation potential than any other substance, with the exception of elemental fluorine. In AOP systems, the highly unstable hydroxyl free radicals react with dissolved waterborne contaminants in a series of strong oxidation reactions. This process happens almost instantaneously, killing 99.99% of all viruses and bacteria and leaving nothing behind but pure, oxygenated water. AOP systems are synergistic in the sense that they multiply the power of the precursor oxidants (like ozone) to yield more disinfection potential than the sum of the two inputs taken separately (i.e. the sum is greater than two parts).

Features / Specifications:

• For residential in-ground swimming pools up to 25,000 gallons
• Flow Rate: Maximum 20 GPM
• Wall Mount Only
• Inlet and Outlet 3/4" PVC Socket
• Rated for Indoor and Outdoor Installation
• Electrical: 110/240VAC 50/60 HZ, 1Ø, 0.3 Amps
• Unit size: 16.7" H × 11.9" W × 3.2" D | Shipping size: 22" x 13.5" x 10.75"
• Unit weight: 9.2 lbs | Shipping weight: 14 lbs
• Listings: UL, cUL, NSF
• Previously known as DEL Ozone Solar Eclipse 50

This unit utilizes one Germicidal UV Lamp (13,000 hour life expectancy, or approx. 18 months) and two 9-1056-01 APG Ozone Modules (5 year life expectancy). Product includes an 18 month warranty on UV Lamp, and 2 year parts warranty on all other components.

Warranty Coverage: CMP UV Systems come with an 2 Year Limited Manufacturers Warranty. The manufacturer warrants this UV System against defects on workmanship and materials. This warranty will be void if this UV System is damaged as a result of improper installation or use, or if damage is a result of ice. The warranty does not cover any labour charges, cost of lost water or chemicals, or any other damages that may occur.

Start a Warranty Claim: To begin a claim please email customerservice@poolsuppliescanada.ca with a photo showing the defect(s)/damage to your UV System and include a brief explanation of what occurred.
