Product Code:

94030194

Product Name:

Magnum

Manufacturer:

Carvin

Compatible with:

Inground Pools

Horsepower:

1.5 HP

Connection Size:

2 Inch Female Threaded

Basket Size :

5.8 Inch Length X 8.75 Inch Width

Voltage:

115/230 V

Warranty:

2 Years

Replacement Parts:

View Online

Return Policy:

Final Sale

The Carvin Magnum 1.5 HP Inground Pump with Ring-Lok™ is an exclusive, efficient locking system that allows quick and easy access to all elements requiring maintenance without disturbing the plumbing fittings. It features a floating washer between the closed impeller and the multi-valve diffuser that ensures improved efficiency and performance for maximum pressure and flow. The Magnum's housing is molded from a single reinforced, corrosion-resistant thermoplastic piece with two drain plugs for easy winterization, and features a 183 cubic inch (3000 cm3) pre-filter. The Magnum's mechanical seal features identical ceramic and carbon surfaces, and all other components are made of BUNA-N rubber and stainless steel. The Magnum's seal is heat and leak resistant.

Features:

• 1.5 HP Inground Pump
• Patented air-cooled heat-sink allows pump to run dry without damage to shaft seal
• Exclusive dual Ring-Lok™design gives "tool free" access to strainer basket and pump internals
• 208 cu. in. (3411 cm³) heavy-duty strainer basket with exclusive priming tube for superior priming capabilities
• Exclusive flap prevents debris in the pump strainer, skimmer basket and filter from flowing back into the pool. The flap also prevents residual hot water in the heater from flowing into filter and causing damage to grids, valves, gaskets etc
• Internal ribs in large strainer basket assure flow, even when filled with leaves and debris
• One-piece case eliminates bolts and gaskets and provides for quiet operation, yet no tools are required for disassembly
• Floating eye seal between closed impeller and diffuser maximizes efficiency
• Maximum water temperature 104 °F (40 °C)
• Energy saver motor standard on all single speed pump units
• 5 Inch basket
• Voltage: 115/230V
• 2 Inch Unions



Warranty Coverage: 2 Year Manufacturer’s Limited Warranty. Coverage includes replacement parts only and is subject to the manufacturer’s discretion. The pump must be installed with a pool or spa. Improper use or installation voids the warranty.
